The Shadow device is designed to protect the car from theft.
The operation of the device is based on the interaction between the Vehicle and the device through the car's digital data bus. The anti-theft device reads various parameters of the vehicle and prohibits.
The operation of the actuators if an unauthorized movement of the
car is attempted.
Disarming is done by entering the PIN code from the car buttons or by placing a Bluetooth tag nearby.
1. Turn on the ignition and enter the current PIN code for authorization;
2. Within 20 seconds after authorization, press the service button 7 times to enter the PIN code change mode;
3. Enter the new PIN code using the car buttons available for recording the code (specified by the installation specialist in the note on page 13). Each press will confirm with a single indication;
4. After entering the new PIN code, the indication will work 3 times and you need to repeat the new PIN code for confirmation. If they match, the new PIN code will be written to memory, and the indication will work 2 times.
If the indication works 4 times, the PIN code will remain the same, since the confirmation code did not match. A repeated attempt to record will be available in 5 seconds, which will be confirmed by the indication turning on once every 3 seconds.
Turn on the ignition, enter the PIN code, and no later than 20 seconds, press the service button 5 times, after which the system will go into service mode, which will be confirmed by a five-time indication.
EXITING SERVICE MODE
To exit service mode, enter the current PIN code with the ignition on.
Everyone knows that the most stolen cars are Lexus and Toyota.
So how can you protect them from theft?
Anti-theft protection for Lexus with the digital anti-theft system Shadow.
The owner is authorized using Bluetooth tags or a pin code with the car's buttons. The main advantage of the system is its size, thanks to which the device is difficult for an intruder to find.
